| Quantity: | |
|---|---|
| Pressure range | -1-0~1 bar…600 bar optional |
| Output | 4~20mA,0~5V/0~10V/0.5~4.5V |
| Power supply | 12VDC~36VDC |
| Accuracy | 0.5%F.S, 1%F.S |
| Pressure port | G1/4''; G1/2'';1/4''NPT or by customized |
| Electronic Port | DIN43650 Hirschman,Direclty cable,M12 4 Pin |
| Working temperature | 35°C ~+125°C |
| Storage Temp | -40°C~125°C |
| Temp Compensation | 0°C~50°C |
| Zero temp drift | ≤0.02%F.S/°C/year |
| IP rating | IP65 |
| Pressure range | -1-0~1 bar…600 bar optional |
| Output | 4~20mA,0~5V/0~10V/0.5~4.5V |
| Power supply | 12VDC~36VDC |
| Accuracy | 0.5%F.S, 1%F.S |
| Pressure port | G1/4''; G1/2'';1/4''NPT or by customized |
| Electronic Port | DIN43650 Hirschman,Direclty cable,M12 4 Pin |
| Working temperature | 35°C ~+125°C |
| Storage Temp | -40°C~125°C |
| Temp Compensation | 0°C~50°C |
| Zero temp drift | ≤0.02%F.S/°C/year |
| IP rating | IP65 |
