4-20mA DN25 Output Flowmeter Easy To Install, High Precision Flowmeter Liquid Turbine Flowmeter

4-20mA DN25 Output Flowmeter Easy To Install, High Precision Flowmeter Liquid Turbine Flowmeter

KLWGY series turbine flow sensor (hereinafter referred to as sensor) is a speed-type flow meter based on the principle of torque balance.It is widely used in petroleum, chemical industry, metallurgy, water supply,papermaking and other industries. It is an ideal meter for flow measurement and energy saving.

Quantity:
Availability:





Inquire Add to Basket

Product Description

液体涡轮流量计 - 副本拷贝

Nominal diameter（mm）	Flow range （m3/h）	Accuracy	Explanation
DN4	0.04-0.25m3/h	±1.0%	KLWGY: pulse type, 24VDC power supply; KLWYB: battery-powered on-site display type; KLWYC: On-site display/4~20mA two-wire current output; KLWYD: RS485 communication output;
DN6	0.1-0.6m3/h
DN10	0.2-1.2m3/h
DN12	0.2-2m3/h	±0.5%
DN15	0.6-6m3/h
DN20	0.7-7m3/h
DN25	1-10m3/h
DN32	1.5-15m3/h
DN40	2-20m3/h
DN50	4-40m3/h
DN65	7-70m3/h
DN80	10-100m3/h
DN100	20-200m3/h
