Advantage：
Remote transmitter option with factory-mounted cables and connectors;
No moving parts resulting in less wear and tear;
Bidirectional accuracy;
Unrestricted flow tube for minimal pressure loss even at high flow rates.
Highlight:
Integrated standard IrDA interface, IIoT Wireless Communication Module RS232 / RS485 with MODBUS RTU protocol, encoder interface module, with sensus protocol;
Approved to the international water meter standard ISO 4064 specifications;
Display with touch keypad;
No moving parts - not prone to wear S and tear in the usual way.
Specification：
| Pipe size | DN10~DN3000mm |
| Medium | conductive liquid,slurry |
| Conductivity | ≥ 5 μS/cm |
| Accuracy | ±0.5% |
| Repeatability | ±0.1% |
| Rated Pressure | 0.25, 0.6, 1.0, 1.6, 4.0MPa (or specified by customer) |
| Display | Instantaneous flowrate, total flow, velocity, flowrate percentage with back light |
| Signal output | 4~20mA current output, pulse output, RS-485, Hart, |
| Power supply | 220VAC, 24VDC |
| Convert type | Compact, remote |
| Protection grade | IP65 (Compact) / IP68 (Remote) |
| Explosion proof | Exia IIC T4 |
| Velocity | 0.3 ~ 12m/s( 0.1 ~ 15m/s as required) |
| Flowing direction | Forward, Reverse |
| Electrode material | 316L, Pt, Ta, Ti, HB, HC, WC |
| Electrode type | Standard fixed type, blade type |
| Electrode numbers | 3 pcs |
| Flange material | SS / CS |
| Alarm(normal open) | Empty, excitation, upper / lower limit |
| Ambient | -25 ~ +60ºC, Humidity: 5 ~ 90% |
| Communication | RS-485 / Hart |
