| Quantity: | |
|---|---|
| Model | Flow Specification | NOMINAL DIAMETER(M3/h) | Flow Range(M3/h) | Turndown Ratio | Starting Flow(m3/h) | Maxmum Pressure Loss | Accuracy |
| KKQY-25(D) | G16 | 25 | 0.5~25 | 50:1 | 0.06 | 0.06 | |
| KKQY-40(D) | G16 | 40 | 0.5~25 | 50:1 | 0.06 | 0.06 | 1.6 |
| G25 | 0.5~40 | 80:1 | 0.05 | 0.08 | |||
| KKQY-50(D) | G40 | 50 | 0.65~65 | 100:1 | 0.06 | 0.1 | |
| G65 | 0.65~100 | 160:1 | 0.06 | 0.2 | |||
| KKQY-80(D) | G100 | 80 | 1.0~160 | 160:1 | 0.07 | 0.3 | |
| G160 | 2.0~250 | 125:1 | 0.10 | 0.3 | |||
| KKQY-100(D) | G160 | 100 | 2.0~250 | 125:1 | 0.10 | 0.3 | |
| G250 | 2.5~400 | 160:1 | 0.15 | 0.45 | |||
| G400 | 4.0:650 | 160:1 | 0.6 | 0.45 | |||
| KKQY150(D) | G400 | 150 | 4.0~650 | 160:1 | 0.7 | 0.5 | |
| G650 | 6.5~1000 | 160:1 | 0.75 | 0.5 | |||
| KKQY-200(D) | G650 | 200 | 6.5~100 | 160:1 | 0.9 | 0.7 | |
| G1000 | 10~1600 | 160:1 | 1.2 | 0.7 |
| Model | Flow Specification | NOMINAL DIAMETER(M3/h) | Flow Range(M3/h) | Turndown Ratio | Starting Flow(m3/h) | Maxmum Pressure Loss | Accuracy |
| KKQY-25(D) | G16 | 25 | 0.5~25 | 50:1 | 0.06 | 0.06 | |
| KKQY-40(D) | G16 | 40 | 0.5~25 | 50:1 | 0.06 | 0.06 | 1.6 |
| G25 | 0.5~40 | 80:1 | 0.05 | 0.08 | |||
| KKQY-50(D) | G40 | 50 | 0.65~65 | 100:1 | 0.06 | 0.1 | |
| G65 | 0.65~100 | 160:1 | 0.06 | 0.2 | |||
| KKQY-80(D) | G100 | 80 | 1.0~160 | 160:1 | 0.07 | 0.3 | |
| G160 | 2.0~250 | 125:1 | 0.10 | 0.3 | |||
| KKQY-100(D) | G160 | 100 | 2.0~250 | 125:1 | 0.10 | 0.3 | |
| G250 | 2.5~400 | 160:1 | 0.15 | 0.45 | |||
| G400 | 4.0:650 | 160:1 | 0.6 | 0.45 | |||
| KKQY150(D) | G400 | 150 | 4.0~650 | 160:1 | 0.7 | 0.5 | |
| G650 | 6.5~1000 | 160:1 | 0.75 | 0.5 | |||
| KKQY-200(D) | G650 | 200 | 6.5~100 | 160:1 | 0.9 | 0.7 | |
| G1000 | 10~1600 | 160:1 | 1.2 | 0.7 |
