| Media type | Liquid |
| Measure range | 1---150cm/s(water) 3---300cm/s(oil),20---3000cm/s(air) |
| Accuracy | ±1 to ±10cm/s |
| Response time | 2-10s |
| Working pressure | 100bar |
| Medium temperature | -20~80℃ |
| Thread | G1/2, G1/4 Male Thread/ M18 Female Thread |
| Power supply | 24VDC, 220VAC |
| Output signal | PNP,NPN,relay |
| Sensor length | 15mm, 20mm, 30mm, 40mm, 60mm |
| Max. temperature gradient of medium | 300K/ min |
| Protect | Reverse/ Short/ Overload |
| Material | Sensor: stainless steel Body: ABS or stainless steel |
| Power connector | M12 connector with 1m cable |
| Protection grade | IP67 |
| Packing | Carton box, each flow switch is individually packaged |
