Industrial Glass Electrode Ph Meter PH Controller with High Low Alarm OEM ORP Meter

Acidity meter (also known as pH meter) is an instrument used to measure the pH value of a solution, and the method for measuring the pH value of an acidity meter is a potentiometric method. In addition to measuring the acidity of the solution, it can also measure the electromotive force (mV) of the battery. It is mainly composed of three parts: reference electrode(calomel electrode), indicator electrode (glass electrode) and precision potentiometer. When measuring, the glass electrode is used as the indicating electrode, and the saturated calomel electrode (SCE) is used as the reference electrode to form a battery.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Mode	KK-PH160
Display	2.8-inch monochrome LCD display, resolution 128*64
Dimensions	96x96x112mm
Hole Size	92x92mm
Weight	1.0kg
Measure range	pH:0.00-14.00pH
	ORP:-1000~1000mV
	-2000~2000mV(customized)
Accuracy	pH:±0.02pH;ORP:±lmV
Input resistance	>1012Ω
Temp.Comp	NTC10K:-10~60℃ accuracy :±0.3℃
Temp.Comp	-10~130℃Manu/Auto
Current output	Isolated type, 4~20mA can be set to correspond to pH/ORP and temperature
Measure range	The maximum load is 750Ω, the output accuracy is ±0.2%FS
Alarm function	2 channels, capacity AC250V/3A, normally open
Relative humidity	10~85%RH（10~85%RH）
Working Temp.	0~60°℃
Power supply	220VAC 50
Power supply	24VDC
