1. Ultrasonic water meter uses ultrasonic measurement method and adopts high quality ceramic transducer to ensure high accuracy and stability; No mechanical movement, no wear, not susceptible to bad water quality and low maintenance cost.
2. This series of water meter is developed and produced according to Chinese National water meter standard GBT/778.1-2018, International water meter standard ISO4064-1:2014 and other standards.
3. This series of water meter adopts the unique ultrasonic propagation phase and time difference measurement technology developed by the company, which has the characteristics of high precision, low power consumption, wide measuring range ratio, stability and reliability.
4. This series of water meters reach IP68 protection grade, applicable to a wide range of occasions.
5. This series of water meter solves the traditional water meter idling, small flow does not measure, pressure loss is too large and other problems. It can be widely used in urban water supply pipeline, household water consumption meter, water resource intake monitoring, farmland irrigation, and also suitable for a variety of industrial sites.
1.Using ultrasonic measurement technology, no mechanical moving parts, small pressure loss, reduce the loss of water pump power, reduce the cost of water supply enterprises.
2. Adopts ultrasonic measurement method, can make the measurement range of higher precision, high reliability, can work in any traffic for a long time point, strong resistance to electromagnetic interference.
3. The design scheme with low power consumption, single section battery continuous working time more than 6 years.
4. Low initiating flow, high accuracy degree.
5. Work in the power supply voltage, ultrasonic transducer failures, such as when a failure has fault judgment, record and display function, can be real-time monitoring of battery, temperature, flow, record down the date and the time of the valid data.
6. Can realize the flow, temperature, characteristics of RS - 485, M - BUS188, NB - IoT, LoRa optional communication a variety of ways.
7. DN15 ~DN50 full range size design, can meet the demand of different scenarios.
Specificationand model | Nominal caliber | Accuracy class | Minimum flow | Boundary flow | Common traffic | Overload flow | Minimum indication value | Maximum indication value |
mm | grade | M³/h | M³ | |||||
LXS-15C | 15 | 2
| 0.031
| 0.050
| 2.500
| 3.125
| 0.0001 | 9999 |
LXS-15E | ||||||||
LXS-20C | 20 | 2
| 0.050
| 0.080
| 4.000
| 5.000 | 0.0001
| 9999
|
LXS-20E | ||||||||
LXS-25C | 25 | 2
| 0.079
| 0.126
| 6.300
| 7.875 | 0.0001
| 9999
|
LXS-25E | ||||||||
LXS-40C | 40 | 2
| 0.200
| 0.320
| 16.00
| 20.00 | 0.0001 | 9999
|
LXS-40E | ||||||||
