Digital Display Oval Gear Flowmeter Measuring Oil Stainless Steel Circular Gear Flow Meter

Digital display Oval gear flowmeter Measuring oil stainless steel circular gear flow meter

Model number project	LC-A cast iron		LC-E cast steel		LC-B stainless steel
Nominal pressure/MPa	1.0 1.6		2.5 4.0 6.4		1.0 1.6
Viscosity of the liquid being measured	2-200mPa.s
The temperature of the liquid being measured	-20℃~+100℃
Flow range m3/h
Model number Precision class DNmm	LC-A cast iron		LC-E cast steel		LC-B stainless steel
Model number Precision class DNmm	0.5%	0.2%	0.5%	0.2%	0.5%	0.2%
10	0.08~0.4	0.1~0.4	0.08~0.4	0.1~0.4	0.1~0.5	0.1~0.5
15	0.25~1.5	0.3~1.5	0.25~1.5	0.3~1.5	0.3~1.5	0.3~1.5
20	0.5~3	0.6~3	0.5~3	0.6~3	0.6~3	0.6~3
25	1~6	1.2~6	1~6	1.2~6	1.2~6	1.2~6
40	2.5~15	3~15	2.5~15	3~15	3~15	3~15
50	4~24	4.8~24	4~24	4.8~24	4.8~24	4.8~24
80	10~60	12~60	10~60	12~60	12~60	12~60
100	16~100	20~100	16~100	20~100	20~100	20~100
150	32~190	38~190	32~190	38~190	38~190	38~190
200	34~340	68~340	34~340	68~340	68~340	68~340
