portable handheld ultrasonic flow meter utilizes two transducers that function as both ultrasonic transmitters and receivers. The handheld ultrasonic flow meter are clamped on the outside of a closed pipe at a specific distance from each other. The transducer of ultrasonic flow meter can be mounted in V-method where the sound transverses the pipe twice, or W-method where the sound transverses the pipe four times, or in Z-method where the transducers are mounted on opposite sides of the pipe and the sound crosses the pipe once.
Handheld ultrasonic flowmeters measure liquid flow with an external clip-on sensor. The installation process is extremely simple, and the all-Chinese man-machine interface makes it easier to operate. Especially suitable for flow balance test and flow monitoring: drinking water, river water, sea water, cooling water, hot water, industrial sewage, lubricating oil, diesel oil, fuel oil, chemical liquids, etc
| Product Name | Hanheld /Portable Ultrasonic Flow Meter |
| Accuracy | +-1%, flow speed >0.32m/s |
| Pipeline Diameter | 32mm~1000mm |
| Liquid | Pure water, tap water etc, 30 +pure liquid |
| Temperature | Meter: -30~90℃; sensor: -30~160 |
| Humidify | Meter: 85%, sensor protection degree: IP67 |
| Power Supply | 90~230VAC (12hours when fully charged |
| Installation | external mounting |
| Housing material | antiflaming ABS |
| Signal output | pulse output (pulse 6-1000ms) |
| Data connection | RS232, baud rate 75~57600 |
1、Non-contact measurement, small size, light weight, easy to carry.
2、The installation of the sensor is simple and easy, and it is used to measure various sizes of pipe sound conducting media.
3、The measurement process does not need to destroy the pipeline, do not need to stop production, the sensor does not contact the measured medium, no pressure loss.
4、Suitable for measuring metal pipes, plastic pipes and pipes of other sound transmitting materials.
5、Built-in rechargeable battery, continuous working time more than 12 hours.
6、Intelligent on-site printing function to ensure the integrity of traffic data.
7、Single/double channel is easy to carry, mobile measurement is suitable for scientific research and measurement calibration.
8、Thickness measuring function.
