KLPH SERIES
KUNKE ANDAO
Specification Of Digital PH Meter
| Model | APX1-G2D | |
| Sensor input | pH | Glass pH sensor(Compatible with grounded PH sensor) |
| ORP | ORP sensor (Platinum/Gold sensor) | |
| TEMP | NTC10K(B) | |
| Measurement range | pH | -2~16pH |
| ORP | ±2000mV | |
| TEMP | -10~150ºC /14~302ºF | |
| Resolution | pH ORP TEMP | 0.01pH 1mV 0.1ºC/ 0.1ºF |
| Meter performance | Accuracy | 0.1% of the measuring range Or PH: ±0.02pH /ORP: ±2mV |
| Sensor diagnosis | Display images and the buzzer prompts briefly | |
| Relay output | Two SPST relays with a maximum load of 3A/250VAC | |
| Analog output | Two 0/4~20mA current output with a maximum load of 1000Ω | |
| Communication | A two-wire RS485 interface | |
| Protocol | MODBUS RTU, support JSON text data format | |
| Display screen | 3.2 inch LCD screen | |
| Protection grade | IP66 | |
| Operating temperature | 0~60ºC | |
| Operating humidity | Less than 95% RH, non-condensing | |
| Storage temperature | -20~70ºC, less than 55% RH, non-condensing | |
| Configuration | Power failure protection, indefinite retention of parameters | |
| Enclosure material | Enhanced ABS | |
| Meter dimension | 100*100*120 mm | |
| Mounting method | Panel mounting (Installation hole size 92*92mm) | |
| Electrical interface | Three M12*1.5 gland are reserved at the back of the instrument; the wire diameter is 3~6.5mm | |
| Power source | 18~36VDC | |
| Power consumption | About 3W | |
| Weight | About 500g | |
